| Brand Name: | SHX |
| Model Number: | SCF330 |
| MOQ: | 1 Set |
| Price: | Negotiable |
| Packaging Details: | Standard export packing |
| Payment Terms: | T/T, L/C |
SHX 300kva Cummins Diesel Generator Set 240kw Silent Generator
Features
1) Universal design and manufacture
2) Most widely used around the world
3) With most service terminals
4) Engineers are familiar with Cummins powered gensets
5) You could find spare-parts very easy
Technical Specifications
|
Genset model |
SCF330 |
|
Genset rated power |
240KW/300KVA |
|
Rated voltage |
400/230V (adjustable) |
|
Rated current |
432A |
|
Frequency |
50Hz |
|
Power factor |
0.8 Lagging |
|
Connecting type |
3 phase 4 wire |
|
Cooling system |
Closed cycle water-cooled with radiator |
|
Overall dimension (L×W×H) mm |
3600×1350×2000 |
|
Weight (kg) |
1900 |
|
Diesel Engine |
|
|
Brand |
Cummins |
|
Model |
6LTAA9.5-G1 |
|
Engine type |
6 cylinders in line, 4 stroke, air-to-air after-cooled |
|
Aspiration |
Turbocharged |
|
Rotating speed |
1500 RPM |
|
Engine cooling system |
Water-cooled |
|
Speed governing system |
Electronic speed governor |
|
Starting method |
By 24V batteries |
|
Engine filter system |
Dry type air filter ,fuel filter, oil filter, water filter |
|
Displacement (L) |
9.5 |
|
Bore×Stroke (mm) |
116.5×148 |
|
Compression ratio |
16.6: 1 |
|
100% Load fuel consumption (g/kw.h) |
≤208 |
|
Lube capacity (L) |
28 |
|
Alternator |
|
|
Brand |
Farrand |
|
Model |
FLD444D |
|
Excite type |
Brushless self-excited AVR regulation |
|
Connecting type |
3 phase 4 pole |
|
Steady frequency change |
0.50% |
|
No load voltage |
≥95%-105% |
|
Steady voltage |
≤±1% |
|
Insulation class |
Class H |
|
Protection grade |
IP23 |
|
The components of the genset |
|
|
(1) Diesel engine; (2) Alternator; (3) Radiator assembly; (4) Control panel; (5) Base frame; (6) Canopy. |
|
SHX Soundproof Generator Set Features:
A new kind of acoustic material is used as pugging, noise reducing return-flow wind tunnel is used as generator
set's ventilation system, and louver is installed in the window to prevent rains and other intruders. High efficiency
silencer with double level structure and another silencer between two levels keep the noise at the lowest level.
The box is modular structure with indicator and maintenance doors which make installation, operation and maintenance
very convenient. Benefited from the special design, medium low noise diesel generator set's noise can be as low as
70dB (A) (at LP7m). Fuel tank can be installed on it according to customer needs.
Sunkings’ Guarantee for SHX Series Generators
1) Guarantee Period: One year or 1000hours whichever comes first.
2) During the guarantee period, the spare-parts will be sent through your shipping agency in China.
3) Spare-parts can also be sent through FEDEX or DHL, but the shipping cost will be charged on both sides for 50%.
4) 24 hours service hotline is available for customers.
OEM Service:
Guangdong Sunkings Electric Co., Ltd. Can provide professional OEM Service for customers.
1. Unique design and manufacture of generator according to customer’s requirement.
2. Customer logo printing or painting on the genset.
3. Installation and Operation manual neutral or headings can be design according to customer’s requirement.
4. Full warranty cover to support the customers.
|
|
