Cummins Diesel Generator Set
>
2300L Big Power Diesel Generator 1MW Diesel Genset 1000kw 85db

2300L Big Power Diesel Generator 1MW Diesel Genset 1000kw 85db

Brand Name: SHX
Model Number: SCF-1375
MOQ: 1 SET
Price: USD 120000-150000/SET
Packaging Details: Plyfilm or plywood
Payment Terms: L/C, T/T, Western Union, MoneyGram
Detail Information
Place of Origin:
China
Certification:
ISO, CE, Soncap, EPA
Engine Type:
Electric Injection
Fuel Tank Capacity:
2300L
Silent Generator Canopy Noise Db::
85db @7m
Generator Standby Power:
1000kw/1250kva
UK Deepsea Contrller::
7320
Circuit Breaker Amper::
2000A
Supply Ability:
15 Sets per Month
Highlight:

2300L Big Power Diesel Generator

,

Big Power Diesel Generator 85db

,

Diesel Genset 1000kw

Product Description

Big Power Generator Genset 1MW Diesel Generator Powered 1000kw

UK Origin Diesel Engine:

Engine model
QSK38-G2
Engine speed (rpm)
1500

Prime power
Standby power
Gross engine power (kWb)
1106
1217
Typical Genset electrical output 0.8pf 25ºC (100 kPa) (KW)
1002
1108
Cylinders
12-cylinder, 60° Vee
Cycle
4 stroke
Induction system
Turbocharged
Combustion system
Direct injection
Compression ratio
13:1
Bore * Stroke (mm)
160 * 190
Engine model
4012-46TWG2A
Engine speed (rpm)
1500

Prime power
Standby power
Gross engine power (kWb)
1106
1217
Typical Genset electrical output 0.8pf 25ºC (100 kPa) (KW)
1002
1108
Cylinders
12-cylinder, 60° Vee
Cycle
4 stroke
Induction system
Turbocharged
Combustion system
Direct injection
Compression ratio
13:1
Bore * Stroke (mm)
160 * 190



Silent Performance Features:

● More than 2mm thick steel to make the canopy.
● High quality paint materials and strict powder paint processing.
● large-scale impedance combined type silencer effectively reducing noise of the generator.
● Stainless steel door locks and hinges and 180° revolvable and disassemble door for easy maintenance.
● High quality soundproof and insulation materials could efficiently reduce noise.
● Transparent viewing window make the control panel clear at a glance.
● Lifting ear is mounted in the base frame for easy pull.
● Elegant appearance and reliable quality.
●From 10kva to 700kva we use normal silent canopy, more than 700kva we are using containerized canopy.
